Nordson TAH 7700846 Static Mixer (nozzles) for Air Spraying
TAH 161-236LL) / Nordson 7700846 Static Mixer (nozzles) for Air Spraying
Description: Static Mixer (nozzles) for Air Spraying
Nordson Quick Spray disposable plastic static mixer nozzles 7700920 is used for low-pressure air-assisted spray system for two-component coatings. This disposable static mixer is designed for use with conventional meter/mix equipment or with Nordson’s two-component cartridge system.
Static Mixer 7700846 Specifications
| Property | Value | Property | Value |
| Product | 7700846 | Element Material | Polypropylene |
| Old Product Number | TAH 160-624AA-4 | Housing Material | Polypropylene |
| # of Elements: | 24 | Tip Style | Air Cap Assembly*** |
| ID inch | 0.24 | Max Housing Pressure* | 360 |
| ID mm | 6.3 | Max Housing Pressure** | 25 |
| Length inch | |||
| Length cm |
*psi at 75°F
**bar at 30°C
***170-AN-200
